Atributos
TZTMarca
95169Número de Modelo
Guangdong, ChinaLugar del origen
Rubidium OscillatorDescripción
GNSS-RB-SR0100Especificación
107 x 55 x 275mm (including the connector length)Tamaño/dimensión
Product Name:Rubidium Oscillator
Weight:1.9KG
Model:GNSS-RB-SR0100
Power supply:DC14.5 - 15.5V start < 30W, stable < 15W
GNSS antenna power supply:DC+5V/100mA
GNSS receiving type:GPS, BDS, GAL, GLO, QZSS, single/double or multiple combination
Size:107 x 55 x 275mm (including the connector length)
1PPS characteristics:square wave, 3.3Vpp, 10% duty cycle, 1ns rising time
10M characteristic:sine wave, +12dBm amplitude
DB9 interface:GNSS NMEA protocol output, rubidium clock internal information output
Unidades de venta:Artículo individual
Tamaño del paquete:30X15X10 cm
Peso bruto:1.900 kg
