Atributos
5Husillo de la potencia (kW)
IndiaLugar del origen
8000 - 55000Rango de velocidad del husillo (r. p. A m)
Wk. head, Wheel head, tailstock, CNC controllerLos componentes principales.
6000Peso (KG)
0.001Repetibilidad (X/Y/Z) (mm)
Precisión de posicionamiento (mm):0.001
Garantía:1 año
Aplicación:Tool room, automobile, Crankshafts, Camshafts
CNC SYSTEM:FANUC - OITF / SCHEMINES
Machine Traverese (mm):300 / 500 / 800 / 1000 / 1250 / 1500 / 1800 / 2000 / 2500
Centre Height (mm):100 / 130 / 150 / 180 / 200 / 225 / 250 / 300
Max. Swivel (deg.):± 8°
Rapid Feed Rate (mm / min):7000
Feed motor torque (Nm):7.7
Min incremental feed (mm):0.001
Positioning accuracy (mm):0.001
Profile Ground ball (mm):40 X 5 mm pitch
In-feed stroke:200
Min incremental feed (mm):0.001
Grinding wheel Width (mm):500 50 Thick
Wheel speed (rpm):1800 / 2100
Power (hp):5
Ground ball screw dia. (mm):40 X 5 mm pitch
Speed range (rpm):20 350 Inf. Variable
Spindle nose taper (MT):3 / 4 / 5 / 6
Swiveling range (deg.):-30 to +90
Tailstock centre (MT):3 / 5 / 6
Quill stroke (mm):25
