Atributos
182mm x 182mmTamaño de celda
La mitad de la celda, N-TYPE, TOPCONTipo
22.53%Panel de la eficiencia
Zhejiang, ChinaLugar del origen
1722x1134x30mm(67.80x44.65x1.18in)Talla
LUXNERIMarca
Número de Modelo:LNVB 620-640M Silver Frame
Cell configuration:120(6x20)
Module dimensions:2172x1303x35mm
Weight:20.5kg
Mechanical load test:Front 5400Pa/Rear 2400Pa
Front Glass:3.2mm coated tempered glass
Junction Box:Ip68 rated (3 by pass diodes)
Connectors:Mc4 compatible
Output Cables:4.0mm2;250mm (+) / 350mm (-);Length can be customized
Frame:Anodized aluminium alloy (reinforced high-load optional)
