Atributos
Oxygen-free Tinned Copper WireMaterial conductor
XlpoMaterial aislante
1.5KVTensión nominal
1 * 4.0mm ²Talla
Guangdong, ChinaLugar del origen
62930 IEC131 2x6 mm2Número de Modelo
Marca:PNTECH
Uso:Central
Funda:Xlpo
Tipo:solar pv cable
Rated voltage:AC:Uo/U=1.0/1.0KV DC:1.5KV
Voltage test on completed cable:AC:6.5 KV/ 5min,DC:15 KV/5min
Wire specification:2x6mm2
Ambient Temperature:-40℃~+90℃
Max Temperature at conductor:+120℃
Service Life:25 years(-40℃~+90℃)
Cold bending test:EN60811-504
Damp Heat Test:EN60068-2-78
Weathering/UV-resistance:IEC 62930
Ozone resistance:EN60811-403
